Input Signal Flexibility: It features a multi-functional modulation card accepting 0–135 Ohm resistive, 4–20 mA current, or 2–10 VDC voltage control signals
Torque & Speed: Delivers a robust mechanical torque of 90 in-lb (10 Nm) with a 25-second running time for a 90-degree stroke at 60Hz (30 seconds at 50Hz)
Power Supply: Rated for standard line voltage operating at 110V - 120V AC
Rotation & Mechanical Drive: Operates with a counter-clockwise (CCW) rotation and is equipped with a standard 10mm D-shaft
Auxiliary Switches & Feedback: Includes 3 adjustable auxiliary switches that provide independent high-fire and low-fire position status feedback, critical for safe burner purging and ignition sequence verification
Factory equipped with a 2-1000 Ohm double potentiometer tracking the 90-degree movement
MFG# SQM40.215R11
