Image for Century Dl1076 Standard Effcy Indr Blwr Mtr 5-5/8" 115 V 10.3 A 3/4 Hp 1075 Rpm from HD Supply

Century Dl1076 Standard Effcy Indr Blwr Mtr 5-5/8" 115 V 10.3 A 3/4 Hp 1075 Rpm

Part 274999

MFG PART DL1076

Brand Century

$188.50

Quantity

Add to List Add to Quote

FREE shipping

In lower 48 states

Non-returnable

Cannot be returned or exchanged

Usually ships next day

Product Details

Product Specs

Resources

Century Dl1076 Standard Effcy Indr Blwr Mtr 5-5/8" 115 V 10.3 A 3/4 HP 1075 Rpm
Permanent Split Capacitor
Lead Reversible
Open Construction
Continuous Air Over
MFG# DL1076

Make & Model
Brand	Century
Country of Origin	CHINA
UNSPSC	40101601
UPC	076335056128

Specifications
Amperage	9.5 amp
Frame	48
Horsepower	0.75 hp
Maximum rpm	1075 RPM
Motor Design	Permanent Split Capacitor
Motor Enclosure Design	Open Air-Over
Motor Mounting Type	Band,Ring,Stud
Motor Shaft Rotation	REV
Name Plate RPM	1075 RPM
Number of Phases	1
Number of Speeds	3
Package Quantity	1
Phase	Single
Shaft Diameter	0.5 in.
Shaft Length	4.5 in.
Thermal Protection Rating	Auto
Voltage	115 V

Assembled Dimensions
Product Depth	5.63 in.
Product Height	10.11 in.
Product Width	5.63 in.

Certifications & Standards
AbilityOne
ADA Compliant
Certifications & Standards	No Certifications or Listings
GSA Approved
Made in the USA
TAA/BAA Compliant
UL Listed

HazMat
Hazardous

Packaging Dimensions
Height	6.800
Length	15.700
Size Measure	IN
Weight	19.050
Weight Measure	LB
Width	6.900
